Preface
Advanced Programming Software User Manual
11–26
DF1 Full-Duplex Device Configuration (MicroLogix 1000 Controllers)
The MicroLogix 1000 controllers support full-duplex DF1 protocol via the RS-232
connection to a host computer. You use a 1761-CBL-PM02 cable or a modem to
connect the RS-232 channel.
For more cabling information, refer to the MicroLogix 1000 Programmable
Controllers User Manual, Publication 1761-6.3.
F1 Port COM1
Current Device Full-Duplex (Micro)
F7 Device/Modem/Full-Duplex (Micro) Config.
F9 Save to File
F9
Press a function key
SAVE TO
FILE
F1
PORT
F2
SELECT
DEVICE
ESC exits/Alt-U aborts changes
ONLINE CONFIGURATION
F7
DEVICE
CONFIG
1. To configure the DF1 parameters begin by pressing
CONFIG OFFLINE
CONFIG
DEVICE
CONFIG
F7
. The following
display appears:
F9
Press a function key
SAVE
TO FILE
F1 Baud Rate (PC to SLC) 9600
F2 Parity NONE
F3 Error Check CRC
F4 Use Modem (Flow Control) NO
F5 Dial Phone Number N/A
F6 Modem Init String N/A
F7 Phone Number N/A
F8 Auto Disconnect N/A (minutes)
F9 Save to File
F10 Full Duplex (Micro) Configuration
F1
BAUD
RATE
F4
USE
MODEM
ESC exits/Alt-U aborts changes
Device/Modem/Full Duplex Configuration
F7
PHONE
NUMBER
F10
FULL
DUPLEX
