Creating and Configuring Processor Files
5–11
All data in the SLC 500 program files that are within the MicroLogix 1000
controller’s fixed structure will remain unchanged when converting to a
MicroLogix 1000, except for the following status file elements:
Status File Bit will be set to
S:0/8 0
S:1/5 1
S:2/4 0
S:5/8 0
Viewing the Conversion Error File
When you create a program for a specified processor and later change the processor,
APS checks for advanced programming instructions, structures, addresses, and
addressing modes not permitted in some processors. An “error/warning” file is
created if any of the above items are detected. You must correct all of the errors
before you can successfully save the file.
For example, this file is created if an SLC 5/03 processor configuration is selected
for a program and you later modify the processor type to be a fixed controller or an
SLC 5/01 processor.
Example
The following example uses a program file configured for an SLC 5/02 processor
that contains a Message (MSG) instruction.
1. Create an error file by pressing
CONFIG OFFLINE
CONFIG
PROCSSR
FUNCTNS
F1
, then
CONFIG OFFLINE
CONFIG
CHANGE
PROCSSR
F1
and select an SLC
5/03 processor. Press
CONFIG OFFLINE
CONFIG
SELECT
PROC
F2
.
