Monitoring Controller Operation
16–17
Integer Data File (N7:)
The display below shows the integer data file. There are 101 elements in the file.
The cursor is on N7:23, which has a value of 1098.
Press a function key
N7:23 =
REM PROG
no forces decimal data decimal addr PROC Addr 1
F7 F5
NEXT
FILE
SPECIFY
ADDRESS
F8
PREV
FILE
address 0 1 2 3 4 5 6 7 8 9
N7:0 0 2 3 0 0 0 0 0 0 0
N7:10 0 0 0 0 0 0 0 0 0 0
N7:20 0 0 0 1098 0 0 0 0 0 0
N7:30 0 0 0 0 0 0 0 57 0 0
N7:40 0 0 0 0 0 0 0 0 0 0
N7:50 0 0 0 0 0 0 0 0 0 0
N7:60 0 0 0 0 0 0 0 0 0 0
N7:70 0 0 0 0 0 0 0 0 0 0
N7:80 0 0 0 0 0 0 0 0 0 0
N7:90 0 0 0 0 0 0 0 0 0 0
N7:100 2043
F1
CHANGE
RADIX
Timer Data File (T4:)
The display below shows the timer data file. The cursor in the display area is on the
enable bit (EN) of timer T4:0, address T4:0/EN. There are four timers in the file.
Press a function key
T4:0/EN =
REM PROG
no forces formatted decimal addr PROC Addr 1
F7 F5
NEXT
FILE
SPECIFY
ADDRESS
address EN TT DN BASE PRE ACC
T4:0 0 0 0 01 sec 0 0
T4:1 0 0 0 01 sec. 0 0
T4:2 0 0 0 01 sec. 0 0
T4:3 0 0 0 01 sec. 0 0
F8
PREV
FILE
