Preface
Advanced Programming Software User Manual
20–4
5. Press
CONFIG OFFLINE
CONFIG
XFER
MEM MOD
F8
. The following menu choices appear:
Press a key for desired transfer direction
(file 2, rung 0)
REM PROG
no forces PROC Addr 1
F2
MEM MOD
TO PROC
F1
PROC TO
MEM MOD
6. The prompt line indicates Press a key for desired transfer
direction . Press
CONFIG OFFLINE
CONFIG
PROC TO
MEM MOD
F1
and confirm the transfer by pressing
CONFIG OFFLINE
CONFIG
YES
F8
. If a memory module is not present in the processor, the message:
NO MEMORY MODULE IN PROCESSOR is displayed.
A copy of processor file TOGGLE now resides in the EEPROM. The former
contents of the EEPROM are overwritten. Any Comments, Symbols, or
Documentation Reports associated with
TOGGLE have not been transferred to the
EEPROM. They reside on the terminal’s hard disk with the archive copy of
TOGGLE .
Memory Module to Processor
Suppose an EEPROM containing processor file DRILL1 is installed in the
controller and you want to transfer this file to the processor memory.
1. Begin at the main menu and press
CONFIG OFFLINE
CONFIG
ONLINE
F1
. The following display appears:
