Configuring Your Programming Device for Online Communication
11–21
Function Key Description
[F1] Baud Rate (PC to SLC)
Toggles between 110, 300, 600, 1200, 2400, 4800, 9600, and
19200. The default is 1200.
[F2] Parity
Toggles between None and Even. The default selection is
None.
[F3] Error Check
Toggles between Cyclic Redundancy Check (CRC) and Block
Check Character (BCC) error checking procedures. The
default selection is CRC.
[F4] Use Modem
Toggles between Yes and No. This field indicates if a modem
is being used. If a modem is used you must have flow control
enabled for handshaking. If No is selected, flow control is
disabled and function keys [F5], [F6], and [F8] are inactive. If
you use a modem, you must enter at least one telephone
number to establish communication. The default selection is
No.
[F5] Dial Phone Number ➀
Toggles between Yes, No, Yes-And Always Send Init
String,and No-But Always Send Init String. If set to Yes or
Yes-And Always Send Init String, the telephone number is
dialed. If set to No or No-But Always Send Init String, a direct
connection is made. The default selection is Yes.
[F6] Modem Initialize ➀
Allows you to configure the modem using Hayes commands
before the telephone number is dialed.
[F7] Phone Number
Displays the telephone number that the modem will dial.
Pressing this key displays the telephone directory where a
new number may be selected or entered. The telephone
number is sent immediately following the initialization.
[F8] Auto Disconnect ➀
Allows you to go offline and return without causing the modem
to reĆdial. If set to zero, the carrier will be dropped as soon as
you go offline. The default is zero. The valid range is 0Ć60
minutes.
[F9] Save to File
Allows you to save the established parameters to a user
configuration file that APS will use to automatically setĆup
these parameters the next time you use the software.
[F10] Full Duplex Configuration
Displays the full duplex configuration subĆmenu for modifying
system performance parameters.
➀ Function is only available when [F4] Use Modem is set to Yes.
