Configuring Your Programming Device for Online Communication
11–39
Example Configuration: DF1 Full-Duplex to DH+ via 5/04 Passthru
DF1 to DH+ bridging is allowed via an SLC 5/04 OS401 processor when the
passthru bit is enabled. An example is shown below.
Processor B
SLC 5/04 processor
CH1
Node 23
(octal)
APS 6.0 or later
Node 77
(octal)
CH0
Node 2
(octal)
CH1
Node 14
(octal)
DF1 FullĆDuplex
Link ID=2
19,200 baud
DH+
Link ID=1
57,600 baud
Processor A
SLC 5/04 OS401 processor
S:34/5=1
To program the SLC 5/04 OS401 processors on DH+, use the DF1 full-duplex
driver. As shown in the screens that follow, enter the destination address 19 decimal
for processor A, and enter the destination address 12 decimal for processor B.
F1 Port COM1
Current Device Full-Duplex
F4 Source Address 0
F5 Destination Address 19
F7 Device/Modem/Full-Duplex Configuration
F9 Save to File
F9
Press a function key
SAVE TO
FILE
F1
PORT
F2
SELECT
DEVICE
ESC exits/Alt-U aborts changes
ONLINE CONFIGURATION
F7
DEVICE
CONFIG
F4
SOURCE
ADDRESS
F5
DEST
ADDRESS
Screen for Processor A
