Configuring Your Processor for Online Communication
13–9
Changing the Channel Configuration
CHANNEL 0 CONFIGURATION
Current Communication Mode: SYSTEM
System Mode Driver: DF1 FULL-DUPLEX
User Mode Driver: SHUTDOWN
Write Protect: DISABLED
Mode Changes: DISABLED
Mode Attention Character: /1b
System Mode Character: S
User Mode Character: U
Edit Resource/File Owner Timeout: 60 (seconds)
Passthru Link ID: 1 (decimal)
CHANNEL 1 CONFIGURATION
System Mode Driver: DH-485 MASTER
Write Protect: DISABLED
Edit Resource/File Owner Timeout: 60 (seconds)
Passthru Link ID: 2 (decimal)
F2
UNDO
EDITS
Press a key for desired function
REM PROG no forces EDITS: NONE PROC Addr 1
Channel Configuration
F1
ACCEPT
EDITS
F4
CH0 SYS
CONFIG
F7
CH1 SYS
CONFIG
F10
SELECT
OPTION
F5
CH0 USR
CONFIG
Use the following tables to configure the channels of your processor.
Parameter
Description
Parameter Ċ
Channel 1 SLC 5/03 OS300
SLC 5/03 OS301,
OS302
SLC 5/04 OS400,
OS401
System Mode
Driver
Toggles between
DHĆ485 Master and
Shutdown. The default
is DHĆ485 Master.
Toggles between
DHĆ485 Master and
Shutdown. The default
is DHĆ485 Master.
Toggles between DH +
and Shutdown. The
default is DH + .
Write Protect
Toggles between
Enabled and Disabled.
The default is
Disabled.
Toggles between
Enabled and Disabled.
The default is
Disabled.
Toggles between
Enabled and Disabled.
If enabled, the channel
ignores incoming write
commands. The
default is Disabled.
Edit Resource/File
Owner Timeout
This is the
communication timeout
period (application
layer). Valid range is
1-65535 seconds.
The default is 60.
This is the
communication timeout
period (application
layer). Valid range is
1-65535 seconds.
The default is 60.
This is the
communication timeout
period (application
layer). Valid range is
1-65535 seconds.
The default is 60.
Passthru Link ID Not Applicable
Valid range is
0-65534.
Valid range is
0-65534.
