Preface
Advanced Programming Software User Manual
5–24
Name Size Date
DRILL1 9392 09-12-95
DRILL2 9392 10-07-95
EXAMPLE 929 10-07-95
MIXER 10221 10-15-94
ONOFF 9334 08-04-95
PAINTGUN 9261 07-19-94
RPMCALC 8704 04-27-94
SEQUENCE 8684 10-03-95
STOP_GO 8586 09-28-94
TOGGLE 8695 07-19-94
C:\IPDS\ARCH\SLC500
ESC exits/Alt–U aborts changes
EXPORT PROCESSOR IMAGES
ESC exits
SOURCE:
DESTIN:
F7
DEFINE
DIR
Press a function key or Enter File Name
F3
SELECT
SOURCE
F1
BEGIN
OPER
F4
ENTER
DESTIN
Function Key Description
[F1] Begin Operation
Converts the selected source archive file to an external
processor image.
[F3] Select Source
Selects the highlighted file from the directory window and
places a copy in the file field.
[F4] Enter Destination Prompts you to enter the destination file name.
[F7] Define User Directories
Displays the user directory window. See chapter 3 for more
information.
3. The archived files are shown in the right window. Select the file you want to
convert by cursoring to the correct file and pressing
CONFIG OFFLINE
CONFIG
SELECT
FILE
F3
.
4. Press
CONFIG OFFLINE
CONFIG
ENTER
DESTIN
F4
and enter the destination file name. If the [Enter] key is
pressed without typing in a name, the source name is used as the destination
name.
5. Press
CONFIG OFFLINE
CONFIG
BEGIN
OPER
F1
to start the file conversion process.
