Offline config, And then, The display changes to the following – Rockwell Automation 9323-PA1E USER MANUAL APS 6.0 User Manual
Page 306
Monitoring Controller Operation
16–13
4.
Notice that the status line now displays binary data. Now press
CONFIG
OFFLINE
CONFIG
CHANGE
RADIX
F1
and
then
CONFIG
OFFLINE
CONFIG
HEX/BCD
DATA
F4
. The display changes to the following:
Press a key or enter value
N7:0 =
REM PROG
no forces
HEX/BCD data
decimal addr
PROC Addr 1
address
0
1
2
3
4
5
6
7
8
9
N7:0
0000
0001
0002
0004
0008
0010
0020
0040
0080
0000
N7:10
0000
F7
F5
NEXT
FILE
SPECIFY
ADDRESS
F8
PREV
FILE
F1
CHANGE
RADIX
5.
Notice that the status line now displays hex/bcd data. Press
CONFIG
OFFLINE
CONFIG
CHANGE
RADIX
F1
and then
CONFIG
OFFLINE
CONFIG
ASCII
DATA
F5
. The display changes to the following:
Press a key or enter value
N7:0 =
REM PROG
no forces
ASCII data
decimal addr
PROC Addr 1
address
0
1
2
3
4
5
6
7
8
9
N7:0
\00\00 \00\01 \00\02
\00\04 \00\08
\00\10 \00\20
\00\40 \00\80
\00\00
N7:10
\00\00
F7
F5
NEXT
FILE
SPECIFY
ADDRESS
F8
PREV
FILE
F1
CHANGE
RADIX
