Transferring Program Files
21–17
8. When the HHT is online, the following menu is displayed. If a file already
exists, the system will display
Overwrite existing program? . If the
HHT memory is empty the prompt UPLOAD FROM PROCESSOR will appear.
In either case, press
CONFIG OFFLINE
CONFIG
YES
F2
to continue and upload the file to the APS
terminal or press
CONFIG OFFLINE
CONFIG
NO
F4
to abort the procedure.
File Name: Prog Name:
File Name Type Size(Instr)
0 System 211
1 Reserved 0
2 Ladder 15
OFFLINE UPLOAD DWNLOAD MODE CLR_PRC>
F1 F2 F3 F4 F5
The APS terminal will display a series of status messages while the program file
is being transferred. When the transfer is complete a display similar to the
following appears:
PROGRAM TRANSFER COMPLETED
Press to exit
Term. Addr: 0 Emulation: 5/01
ROCKWELL SOFTWARE INCORPORATED
9323 SERIES SOFTWARE
SLC-500 PROGRAM TRANSFER UTILITY
File Name : EXAMPLE .ACH
A total of 4 data, 4 program, and 2 force table(s)
20 Words in 4 Data Files, 78 Words in 4 Program Files,
2 Words in 2 Force Tables.
There are 0 undefined data and 0 undefined program file(s).
9. At this point you have completed the sending program procedure. At the APS
terminal and HHT press
[ESC][ESC][ESC] to return to the main menu.
