Preface
Advanced Programming Software User Manual
5–8
Configuring Speciality I/O Modules
When you use a specialty I/O module, you must indicate the type of module to APS.
The configuration menu provides a list of available modules from which to select.
Each module is pre-configured, so after selecting the module from the list you have
the option of viewing its configuration by pressing [F9], SPIO Configuration.
Alteration of the fields is not recommended since these fields are pre-configured.
However, if you select a module not listed, you may be required to alter some of the
fields. Refer to your specialty I/O module user manual for more information
regarding the required parameters.
To configure a specialty I/O module not listed, do the following:
1. At the I/O Configuration menu (refer to page 5–4), press
CONFIG OFFLINE
CONFIG
MODIFY
SLOT
F5
. Using
the [down arrow] key or the [END] key, go to the end of the menu and
select OTHER from the list.
2. Refer to your specialty I/O module user manual and enter the module’s ID code
at the prompt. For example, type:
12705 . This is the ID code for the
1746-HSCE module. Press [ENTER] .
3. Press
CONFIG OFFLINE
CONFIG
SPIO
CONFIG
F9
. A screen similar to the following is displayed:
RACK 1 = 1746-A4 4-SLOT Backplane
RACK 2 =
RACK 3 =
SLOT C
*0
*1
*2
*3
4
5
6
7
8
Press a function key
I/O CONFIGURATION FOR:EXAMPLE
F7 F5
G FILE
SIZE
ADVNCD
SETUP
F1
ISR
NUMBER
F3
MODIFY
G FILE
SPECIAL CONFIG FOR SLOT: 1
Module’s ID Code: 12705
Maximum Input Words: 0
Maximum Output Words: 0
Scanned Input Words: 0
Scanned Output Words: 0
M0 Length: 0
M1 Length: 0
‘G’ File Size: 0
ISR Number: 0
ESC exits
ESC exits
