Creating and Configuring Processor Files
5–15
The following function keys operate the same for Rename, Copy, Delete, Copy To
Disk, and Copy From Disk.
Function Key Description
[F1] Processor Memory
The operation is performed on the processor file, but not the
comments, symbols and documentation reports associated
with it. Includes all program files and data files (the part of the
processor file that can be downloaded to a processor, memory
module, or HHT). Files with the extension .ach are affected.
[F3] Comments and Symbols
The operation is performed on the comments and symbols
associated with the file, but not the processor file itself. These
reside on hard disk only. Files with the following extensions
are affected:
.ac$ .b0$ .b1$
.b2$ .ix$ .lx$
.nam .op$ .pc$
.xd$ .xo$
[F4] Documentation Reports
The operation is performed on the documentation reports
associated with the file, but not the processor file itself. These
reside on hard disk only. Files with the following extensions
are affected:
.dtr .lis
.pcr .xrf
[F5] All of the Above
All files associated with a processor file are affected. (i.e.,
processor file, comments and symbols, and documentation
reports.)
These components are discussed in detail later in the chapter.
Copying Archive Files
To illustrate the Copy function, suppose you have created symbols in processor file
DRILL1 and you want to make a copy of them, for use in other processor files.
1. From the offline program display, select
CONFIG OFFLINE
CONFIG
FILE
OPTIONS
F7
, then
CONFIG OFFLINE
CONFIG
COPY
F4
, then
CONFIG OFFLINE
CONFIG
COMMNTS
SYMBOLS
F3
. This brings you to the following display:
