Transferring Program Files
21–11
4. To send program file TRANSFER , start at the main menu on node 0, the sending
APS terminal, and press
CONFIG OFFLINE
CONFIG
WHO
F5
, then
CONFIG OFFLINE
CONFIG
WHO
ACTIVE
F5
.
The Who Active screen appears with a list of the active nodes on the network.
Notice node 3
APS XFER . This indicates that node 3 is waiting to transfer a
program file.
0 TERM (5) 12 24
1 500-20 (5) 13 25
2 5/02 (5) 14 26
3 APS XFER (5) 15 27
4 HHT (5) 16 28
5 17 29
6 18 30
7 19 31
8 20
9 21
10 22
11 23
F2
STATION
DIAGS
Press a key for desired network function
WHO ACTIVE - Active Station Identification
ESC exits
F1
ONLINE
F3
SET
OWNER
F4
CLEAR
OWNER
F7
MAX
ADDRESS
F8
NODE
ADDRESS
F9
NODE
BAUD
5. Position the cursor on node 3 and press
CONFIG OFFLINE
CONFIG
ONLINE
F1
.
PROCESSOR MEMORY CORRUPTED
Press a key, enter file number or file name
REM PROG SLC 5/01 Series A FRN 1 PROC Addr 1
PROGRAM DIRECTORY FOR PROCESSOR: EXAMPLE
FILE PROTECTED NAME TYPE SIZE (words)
0 system *
F1 F2 F3 F4
PROCSSR
FUNCTNS RESTORE
RETURN
TO MENU
CHANGE
LNK ADR
