Creating and Printing Reports
10–5
1. Begin at the main menu and press
CONFIG OFFLINE
CONFIG
OFFLINE
PRG/DOC
F3
, then
CONFIG OFFLINE
CONFIG
CREATE
REPORTS
F6
. The following
display appears:
Press a function key or press ENTER to perform operation
offline SLC 5/03 File DRILL1
Starting File:Rung 2
Ending File:Rung 3
Power Rail YES
Address Comments YES
Address Display SYMBOL
Rung Comments YES
Ladder Cross Reference ALL
Output Cross Reference NO
Save to File
PROGRAM LISTING OPTIONS
F3
TOGGLE
REPORT
F5 F6
REPORT
OPTIONS
GENERAL
OPTIONS
ESC exits/Alt-U aborts changes
F8
TITLE
F2
SELECT
ALL
F4
RESET
REPORTS
DOCUMENTATION
Program Listing
Cross Reference
Processor Config
Data Tables
ESC exits
Two windows are shown in the display area. The window at the right indicates
the types of reports. The cursor is on the Program Listing report.
The window at the left indicates the program listing options for the selected
report. Use the arrow keys to select the type of report. The window at the left
changes according to the type of report you choose.
At this display, you can create one or all of the reports using the default settings
or you can modify the settings. The default options are shown. If subroutine
program files have been created (in this case, file 3 has been created), the
default options will include them in the Ending File entry.
