Restoring and Saving Processor Files
14–3
Changing the Link Address
This option lets you change to another node address to monitor another processor
file.
1. When you are online at the program directory display, press
CONFIG OFFLINE
CONFIG
CHG LINK
ADDRESS
F4
.
2. To attach to node address 2, at the prompt line type: 2 and press [ENTER] . If
the processor program is found on your disk and the processor is not password
protected, the following display appears:
F1 F2 F6 F7 F3 F4 F8
CHANGE
PROCSSR
CHANGE
PASSWRD
CREATE
FILE
DELETE
FILE
CHANGE
PR. NAME
CHANGE
FL. NAME
MONITOR
FILE
Press a key, enter file number or file name
REM RUN L532 Series C Rev.2 PROC Addr 2
F5
CLEAR
MEMORY
FILE PROTECTED NAME TYPE SIZE (words)
0 system 74
1 reserved 0
2 ladder 48
PROGRAM DIRECTORY FOR PROCESSOR: STOP_GO
The above display is for processor file STOP_GO . Notice that the status line
indicates that the APS terminal is communicating with PROC Addr 2 . If you
specify a node address that does not exist or is inactive, the message: ILLEGAL
DATA OR PARAMETER VALUE is displayed.
3. If you are communicating with a processor and the processor loses power, the
message:
MESSAGE TIMEOUTS - LOSS OF COMMUNICATIONS appears.
At this point you can abort by pressing
CONFIG OFFLINE
CONFIG
YES
F8
, or press
CONFIG OFFLINE
CONFIG
NO
F10
to
continue and re-establish communications.
