Creating and Configuring Processor Files
5–23
3.
Press
CONFIG
OFFLINE
CONFIG
ENTER
DESTIN
F4
and enter the destination file name. If the [Enter] key is
pressed without typing in a name, the source name is used as the destination
name.
4.
Press
CONFIG
OFFLINE
CONFIG
BEGIN
OPER
F1
to start the file conversion process.
Archive to Image Operation (SLC 5/03 and SLC 5/04 Processors Only)
The Archive to Image option allows you to convert archive files to processor image
files.
1.
From the File Options menu press
CONFIG
OFFLINE
CONFIG
ARCH TO
F2
. The following menu appears:
ARCHIVE TO IMAGE
ESC exits
F7 Update External Processor Image Tag:
ALLEN-BRADLEY IMAGE FILE
F8 External Format Processor Image File
F9 Save User Preferences
F9
SAVE
PREFS
Press a function key
F7
TAG
F8
PROC
Function Key
Description
[F7] Image Tag
Updates the external processor image tag. Up to 80
characters can be entered.
[F8] Processor Image
Allows you to access the convert processor image functions.
[F9] Save Preferences
Saves the current preferences, including the Processor Image
Tag, to the user preference file.
2.
Access the Processor Image functions by pressing
CONFIG
OFFLINE
CONFIG
PROC
F8
. The following
menu appears:
