Preface
Advanced Programming Software User Manual
10–4
Creating Reports
This section explains how to create the different types of reports for files that are in
the terminal workspace. You have the option of using the default settings that are
displayed, or you can change the default settings to match your requirements. The
file
DRILL1 is used here as an example.
Program Listing Report
The program listing report is similar to the ladder program you view on the terminal
screen. It can include:
•
the main program file and all subroutine files
•
a single file
•
a range of files
•
a range of rungs within a single file
The report shows:
•
instruction addresses and symbols (you can omit symbols)
•
address/instruction comments (you can omit these)
•
rung comments (you can omit these)
•
cross reference data for the addresses in each rung (you can show data for all
addresses, output addresses only, or no addresses)
•
output reference data for the input addresses in each rung (you can enable or
disable this option)
