Preface
Advanced Programming Software User Manual
6–22
2. Press
CONFIG OFFLINE
CONFIG
CREATE
DT FILE
F6
. The prompt line displays Enter Address to create .
Data is created by entering the highest numbered element you want to be
included. For example, entering element
N7:12 (default integer file 7) creates
element N7:12 and all lower numbered elements down to N7:0 , if they have
not already been created.
3. Type the element address: N7:12 and press [ENTER] .
If you accept the file, the Data Table Map is updated as shown below.
FILE TYPE LAST ADDRESS ELEMENTS WORDS FILE PROTECTION
0 O output O:3 1 1
1 I input I:2 2 2
2 S status S:82 83 83
3 B binary or bit B3/15 1 1
4 T timer 0 0
5 C counter 0 0
6 R control 0 0
7 N integer N7:12 13 13
8 F floating 0 0
PROCESSOR MEMORY LAYOUT
100 data words of memory used in 9 data table files
* instruction words of memory used in 3 program files
* instruction words of unused memory available
F6 F7
CREATE
DT FILE
DELETE
DT FILE
Press a key or enter file number
offline no forces EDITS: NONE File EXAMPLE
DATA TABLE MAP
F10
DATA
PROTECT
The Data Table Map indicates that the integer (N) file 7 size is 13 elements
(equivalent to 13 words) and the last address is N7:12. Note the change in the
processor memory layout. The number of data words has increased from 87 to
100. Also, the “instruction words of memory” figures are replaced with
asterisks (
∗
).
Refer to chapter 8 for more information on protecting files.
Note These figures are updated only after the processor file is saved to disk again.
