DH+ WHO Active
The DH
+
WHO Active display allows you to view other active devices on the
network. DH
+
WHO Active works the same as DH-485 WHO, except valid node
addresses range from 0-77 octal.
Access the DH
+
WHO Active display by pressing [F5] Who Active from the APS
Online menu. The following display appears:
00 20 40 60
01 5/04 TEST 21 41 61
02 22 42 62
03 23 43 63
04 24 44 64
05 25 45 65
06 26 46 66
07 27 47 67
10 30 50 70
11 31 51 71
12 32 52 72
13 33 53 73
14 34 54 74
15 35 55 75
16 36 56 76
17 37 57 77 TERM
F2
Station
Diags
Press a function key
WHO ACTIVE - Active Station Identification
ESC exits
Node
F1
Online
Program
Device Type
Name of Program File
Address
Note that the station diagnostics option is only available when using a PLC
processor or when the cursor is on a terminal. If you try to access this function
when the cursor is on an SLC 5/04 processor the error message:
FUNCTION NOT
AVAILABLE is displayed.
Note The program name and program owner fields are only updated when you first enter
the DH
+
WHO function or when the DH+ node configuration changes. For
example, these fields are updated when another node appears or disappears from
the WHO screen.
