Documenting Ladder Programs
7–7
2. The cursor is located on the rung for which you want to add a comment. Press
CONFIG OFFLINE
CONFIG
RUNG
COMMENT
F1
. The following display appears:
( )
B3
12
Enter rung comment for: OTE,B3/12
(file 2, rung 0)
offline
Edit Mode: Insert Col: 1 Line: 1 File EXAMPLE
F9
NEXT
COMMENT
F2
UNDEL
COMMENT
END
F10
PREV
COMMENT
F3
DELETE
LINE
F6 F8
UNDEL
WORD
ACCEPT
/ EXIT
F5
DELETE
WORD
F1
DELETE
COMMENT
F4
UNDEL
LINE
]/[ ] [
B3
10
B3
11
] [
B3
7
Note that the ladder cursor has moved to the output instruction, which will be
associated with the rung comment. An area above the rung is reserved for the
comment. The rung comment cursor appears there.
Function Key Description
[F1] Delete Comment
[F2] Undelete Comment
Deletes and undeletes comments, lines of comments, and
individual words.
[F3] Delete Line
[F4] Undelete Line
Deletes and undeletes line comments.
[F5] Delete Word
[F6] Undelete Word
Deletes and undeletes word comments.
[F8] Accept/Exit
Allows you to accept the rung comment and exit to the
Document menu functions.
[F9] Next Comment
Saves the current comment and moves the cursor to the next
rung, instruction, or address that you can comment.
[F10] Previous Comment
Saves the current comment and moves the cursor to the
output instruction in the previous rung, instruction, or address
that you can comment.
