Battery Commands
Wavecom Autodiag +WDIAG
©Restricted
Page: 103 / 158
This document is the sole and exclusive property of Wavecom. Not to be distributed or divulged without
prior written agreement.
WM_DEV_OAT_UGD_049 - 001 VOLUME 4 August 23, 2007
23.3.5 Examples
Command Responses
AT+WDIAG=0,1,0,3000,4000,0
Note: ADC selfdiagnostic start in “best effort”
for a min and a max trig
OK
Note: Done
AT+WDIAG?
Note: Current value
+WDIAG: 0,1,0,3000,4000,0,0
OK
Note: Done
AT+WDIAG=0,1,60,0,0,50,0
Note: ADC selfdiagnostic start with a 60s
frequency for a delta trig
OK
Note: Done
AT+WDIAG?
Note: Current value
+WDIAG: 0,1,60,0,0,50,0
OK
Note: Done
AT+WDIAG=0,0
Note: ADC selfdiagnostic stop
OK
Note: Done
23.3.6 Notes
Unsolicited responses for self diagnostic are only returned through one port. If these
responses are already activated on a port and if the activation is made on another
port, the command will return "+CME ERROR: 552" specific error.
Values over 4650 mV are not used
After a +WBCI=0 indication (minimum battery level reached), the selfdiagnostic is
stopped.
Only one can be activated at the same time.
