I/O Commands
Wavecom Interrupt Pin Configuration +WIPC
©Restricted
Page: 87 / 158
This document is the sole and exclusive property of Wavecom. Not to be distributed or divulged without
prior written agreement.
WM_DEV_OAT_UGD_049 - 001 VOLUME 4 August 23, 2007
Command Responses
+WIOM: 34,0
+WIOM: 35,0
+WIOM: 36,2
+WIOM: 37,2
+WIOM: 38,2
+WIOM: 39,2
+WIOM: 40,2
+WIOM: 41,2
+WIOM: 42,2
+WIOM: 43,2
+WIOM: 44,0
OK
Note: GPIO
3,4,5,6,7,8,9,10,11,12,13,18,25,36,37,38,39,40,41,42,43
are used by a feature. All others are configured as inputs.
AT+WIPC? +WIPC: 0,1,0,0,1
+WIPC: 1,1,0,0,1
OK
Note: By default, GPIO3/INT0 and GPIO25/INT1 are
configured as interruption pins (high to low edge, de-bounce
processing mode with a duration equal to 7.8 ms)
AT+WIND=2048 OK
Note: Activate the +WIND indications for interruption
Note : Interrupt on INT0
+WIND: 12,0
Note : Interrupt on INT1
+WIND: 12,1
AT+WIPC=1,0 OK
Note: Configure GPIO25/INT1 as GPIO. Only GPIO3/INT0 is
configured as interruption pin
AT+WIPC? +WIPC: 0,1,0,0,1
+WIPC: 1,0
OK
Note: GPIO25/INT1 is configured as GPIO
AT+WIPC=0,1,0,1
Note: the parameter is set
to by-pass
OK
