EB-230 Data Sheet
Ver 1.3
1
PIN Coordinates
Unit:mm
Pin #
X
Y
Pin #
X
Y
1 0.00
0.00
10 12.50
7.62
2 0.00
1.27
11 12.50
6.35
3 0.00
2.54
12 12.50
5.08
4 0.00
3.81
13 12.50
3.81
5 0.00
5.08
14 12.50
2.54
6 0.00
6.35
15 12.50
1.27
7 0.00
7.62
16 12.50
0.00
8 4.06
10.06 17 9.71
-2.44
9 9.71
10.06 18 2.79
-2.44
TRANSYSTEM INC.
An A
+
supplier of RF microwave & GPS products
Ultimate
E
E
B
B
G
G
P
P
S
S
E
E
n
n
g
g
i
i
n
n
e
e
B
B
o
o
a
a
r
r
d
d
EB-230
EB-230 is an ultra miniature 12 x 12 mm
2
GPS engine board. It provides superior
navigation performance under dynamic
conditions in areas with limited sky view like
urban canyons. High sensitivity up to
-158dBm
for weak signal operation without
compromising accuracy. EB-230 is your best
choice for embedded applications.
Key Features :
• Small form factor: 12 x 12 x 3 mm
• Lead-Free – RoHS/WEEE compliant
• High sensitivity -158dBm
• Tracks 32-Channel of satellites
• Fast Position Fix
• Low power consumption
PIN Definition :
Applications :
•
Handheld devices
•
Automotive and Marine Navigation
•
Automotive Navigator Tracking
•
Emergency Locator
•
Geographic Surveying
•
Personal Positioning
•
Sporting and Recreation
•
Embedded applications : PDA, DSC,
Smart phone, UMPC, PND, MP4
