Battery Commands
Wavecom Autodiag +WDIAG
©Restricted
Page: 101 / 158
This document is the sole and exclusive property of Wavecom. Not to be distributed or divulged without
prior written agreement.
WM_DEV_OAT_UGD_049 - 001 VOLUME 4 August 23, 2007
23.3.3 Parameters and Defined Values
: ADC type
0 battery voltage autodiag (default value)
1 ADC auxiliary autodiag
2 Wireless CPU ® temperature (Power Amplifier) in mV
(available for Q2687 only)
: selfdiagnostic activation mode
0 stop (default value)
1 start
: period of ADC reading in seconds
0 best effort, approximately 50 readings per second
(default value)
1 - 3600 fixed period in seconds
: minimum threshold
When this threshold is reached, unsolicited response
+WDIAGI is sent to the user application.
0 trigger deactivated (default value)
3200 - 4300 threshold in mV (for = 0)
100 - 2000 threshold in mV (for = 1 or 2)
: maximum threshold
When this threshold is reached, unsolicited response
+WDIAGI is sent to the user application.
0 trigger deactivated (default value)
3200 - 4300 threshold in mV (for = 0)
100 - 2000 threshold in mV (For = 1 or 2)
: delta threshold
When the delta of the last ADC readings
exceeds the threshold, unsolicited response +WDIAGI is
sent to the user application.
0 trigger deactivated (default value)
10 - 3000 threshold in mV
: number of last values used for the delta calculation
0 5 (default value)
1 10
2 20
