Serial Port Commands
Multi-flow Management +WMFM
©Restricted Page: 158 / 184
This document is the sole and exclusive property of Wavecom. Not to be distributed or divulged without
prior written agreement.
WM_DEV_OAT_UGD_049 - 001 VOLUME 1 August 23, 2007
: data type
0 GSM data
1 GPRS data
: physical port state
0 deactivated
1 activated
8.12.4 Parameter Storage
The and parameters are stored in EEPROM without using AT&W.
8.12.5 Examples
Command Responses
AT+WMFM=? +WMFM: 0,(0-2),(1-3,80)
+WMFM: 1,(0-2),(80,1),(0-1)
OK
Note: To manage incoming data, only UART 1 is
available
AT+WMFM=0,2 +WMFM: 0,2,1,1
+WMFM: 0,2,2,0
+WMFM: 0,2,3,0
OK
Note: Read state of all ports Note: UART1 is opened
AT+WMFM=0,1,2
Note: Open UART2
OK
AT+WMFM=0,2,2
Note: Read UART2 state
+WMFM: 0,2,2,1
OK
AT+WMFM=1,2 +WMFM: 1,2,4,0
+WMFM: 1,2,4,1
OK
Note: Read attachments of ports to which data are
redirected
Note: GSM and GPRS data are dynamic
