Short message Commands

New Message Indication +CNMI

©Restricted

Page:

63 / 202

This document is the sole and exclusive property of Wavecom. Not to be distributed or divulged without
prior written agreement.

WM_DEV_OAT_UGD_049 - 001

VOLUME 3

August 23, 2007

• For =2

Unsolicited response

+CDSI: ,

17.2.3

Parameters and Defined Values

:

processing of unsolicited result codes (see note below)

0

same processing as =2

1

same processing as =2

2

Buffer unsolicited result codes in the TA when TA-TE link is

reserved and flush them to the TE after reservation.

Otherwise forward them directly to the TE.

3

same processing as =2

:

result code indication routing for SMS-DELIVER indications

0

no SMS-DELIVER indications are routed

1

SMS-DELIVERs are routed using unsolicited code +CMTI

(default value)

2

SMS-DELIVERs (except class 2 messages) are routed using

unsolicited code +CMT

3

Class 3 SMS-DELIVERS are routed directly using code in

=2 .

Other classes messages result in indication =1.
