6 0 1 P R O S E R I E S
X L
8 - 1 4
AS/NZS 3551 Controlled Power Sequence and Test Limits for Auto and Step Tests
AS/NZS 3551
STANDARD
DUT OUTLET CLASS I CLASS II CLASS IP
DESCRIPTION POLARITY CIRCUIT B BF CF B BF CF B BF CF
Line Voltage V N/A OFF NL NL NL NL NL NL NT NT NT
Protective Earth
Resistance
Ω
*
N/A OFF 0.2 0.2 0.2 NT NT NT NT NT NT
Insulation Resistance
L1-L2-Case M
Ω
**
N/A OFF 1.0 1.0 1.0 1.0 1.0 1.0 NT NT NT
Startup Delay (Auto
only) Norm Norm
Current in L2 -- A Norm Norm NL NL NL NL NL NL NT NT NT
Patient Leakage
Current --
µA
Norm Norm 100 100 10 100 100 10 100 100 10
Mains on AP – µA Norm Norm NT 5000 50 NT 5000 50 NT 5000 50
Earth Leakage -- µA Norm No E 500 500 500 NT NT NT NT NT NT
Patient Leakage
Current--
µA
Norm No E 500 500 50 NT NT NT NT NT NT
Power Off Delay Norm No L2
No E
Earth Leakage -- µA Norm No L2
No E
1000 1000 1000 NT NT NT NT NT NT
Patient Leakage
Current--
µA
Norm No L2 100 100 10 100 100 10 NT NT NT
*Testing should be done using 1 Amp.
**The Insulation Resistance L1-L2 - Case test is the Insulation Resistance L1-L2 – Protective Earth test as described in
AS/NZS 3551:1996 section 5.3.3 Insulation Resistance test condition 1. The L1-L2 – Enclosure (test condition 2) is not
performed due to hardware limitations.
