HEI 95 Conventional Test Sequence and Test Limits for Auto and Step Tests
DC-Only tests will only be performed if DC readings are enabled. The types (B, BF, and CF) represent
applied parts for Insulation Resistance, Patient Leakage Current, Patient Auxiliary, and Mains on Applied
Part.
HEI-95 STANDARD DUT OUTLET CLASS I CLASS II
DESCRIPTION POLARITY CIRCUIT B BF CF B BF CF
Protective Earth
Resistance
Ω
N/A OFF 0.2 0.2 0.2 NT NT NT
Insulation Resistance
L1-L2- Case M
Ω
N/A OFF 50 50 50 NT NT NT
Insulation Resistance
All-Case M
Ω
N/A OFF NT 50 50 NT NT NT
Startup Delay Norm No E N/A N/A N/A
Earth Leakage µA Norm No E 500 500 500 NT NT NT
Power Off Delay N/A OFF N/A N/A N/A
Startup Delay Reverse No E N/A N/A N/A
Earth Leakage µA Reverse No E 500 500 500 NT NT NT
Power Off Delay N/A OFF N/A N/A N/A
Startup Delay Norm Norm
Enclosure Leakage µA Norm Norm 500 500 500 100 100 10
Enclosure Leakage µA Norm No E 500 500 500 NT NT NT
Power Off Delay N/A OFF
Startup Delay Reverse Norm
Enclosure Leakage µA Reverse Norm 500 500 500 100 100 10
Enclosure Leakage µA Reverse No E 500 500 500 NT NT NT
Power Off Delay N/A OFF
Startup Delay Norm Norm
Patient Leakage Current
µA Norm Norm 500 500 50 100 100 10
Patient Leakage Current
µA Norm No E 500 500 50 NT NT NT
Power Off Delay N/A OFF
Startup Delay Reverse Norm
Patient Leakage Current
µA Reverse Norm 500 500 50 100 100 10
Patient Leakage Current
µA Reverse No E 500 500 50 NT NT NT
Power Off Delay N/A OFF
Startup Delay (Auto
only) Norm Norm
Patient Leakage Current
µA – DC Only Norm Norm 500 500 50 100 100 10
Patient Leakage Current
µA – DC Only Norm No E 500 500 50 NT NT NT
Power Off Delay N/A OFF
Startup Delay (Auto
only) Reverse Norm
Patient Leakage Current
µA – DC Only Reverse Norm 500 500 50 100 100 10
Patient Leakage Current
µA – DC Only Reverse No E 500 500 50 NT NT NT
