6-32 Modular Block System: Hydraulic Presses
Standard Function Blocks SB064
SB064: Safety gate monitoring
Block header
Input parameters
• SSNR: Safety subroutine number
Permitted value range: 1 ... 600
Format: Word constants KF000001 ... KF000600
(see sections in Chapter 5 entitled “Administration data blocks
DB015, DB016 and DB017” and “Input parameter SSNR”).
• GRP: I/O-Group status flag (SafetyBUS p) containing the inputs S1
and S2 (M116.00 for I/O-Group 0 to M116.31 for I/O-Group 31)
If the SB is being used without SafetyBUS p, the input
parameter must be assigned RLO-1
• S1: Gate switch: Signal 1 If the gate is closed, both gate
• S2: Gate switch: Signal 2 switches must supply a 1-signal
• SyTi: Synchronisation time between S1 and S2
Value in ms [0...32767]; 0 = infinite; format: word constants
SB064
ST_K4
W - SSNR
X - GRP
X - S1
X - S2
W - SyTi
X - MRun
X - AuSt
X - ARSt
X - NoFT
X - RSET ENBL - X
