Modular Block System: Hydraulic Presses 6-143
Settings for the parameters TOn and TOff
Poppet valves
I/P Parameter TOff = 0 0< TOff
max
VTyp = 1
TOn = 0 Reaction time is not Reaction time is monitored
monitored when the valve when the valve is
switches on or off switched off
0< TOn
max
Reaction time is Reaction time is
monitored when the valve monitored when the valve
is switched on is switched on and off
Directional control valves
I/P Parameter 0< TOff
max
VTyp = 0
0< TOn
max
Reaction time is monitored when the valve is
switched on and off
Setting reaction times
• Select a low value (e.g. 10 ms)
• Increase the value step by step (max. 10 ms steps), until it is clear that
the valve operates safely and correctly.
This will ensure that the reaction times correspond to the actual values of
the valve.
