Chapter 2: Front panel programming
E-FSA64 and E-FSA250 Technical Reference Manual 85
Advanced programming for panel and loop options is covered in the following
topics in this chapter.
Programming events
Advanced programming lets you create custom responses to these types of
events:
• Panel events
• Loop events
• Panel event corrs (correlations)
Advanced programming for panel and loop events is covered in the last two
topics in this chapter.
Changing loop configuration options
Loop configuration options
Loop configuration includes the following programmable options:
Table 25: Loop configuration options
Option
Description
Loop class Indicates whether the loop is wired Class A or Class B.
Zone Select this option to add a zone.
Correlation Groups Select this option to add correlation groups.
Device Select this option to add devices.
Loop 2 Enable [1] Select Yes to enable Loop 2. Select No to disable Loop 2. [1]
Loop 2 Fst Grp [1] [2] Select:
001 to 025 to combine loop 1 and 2 devices in the same fast
groups
— or —
101 to 125 to use separate fast groups for Loop 2 devices.
[1] Displayed in dual loop systems only.
[2] See “Programming fast groups for sounder bases” on page 93.
Most options have a factory default setting that you can accept or change.
See “Factory default settings” on page 36.
