Chapter 2: Front panel programming
130 E-FSA64 and E-FSA250 Technical Reference Manual
To program panel events:
1. Press the Menu button and choose Program.
2. Choose Advanced Program.
3. Enter a level two password.
4. Choose Panel Events.
5. Select the event to be programmed.
6. Choose Event Notification.
7. Configure the event notification options. See the
default settings in the table above. Not all options
shown here are displayed on all systems.
Printer: Yes or No. This controls whether event
information is sent to the printer
Dialer:
• Acct 1 2: Event information is sent to both
dialer accounts
• Acct 1: Event information is sent to dialer
account one
• Acct 2: Event information is sent to dialer
account two
• None: Event information is not sent to the
dialer
CID: Contact ID event code (000 to 999)
Network: Controls whether event information is
sent to the connected network
8. When you have finished configuring each page,
choose Save.
9. Repeat steps 6 to 9 for each panel event.
10. Press the Menu button to exit menu mode, or
continue programming.
Main Menu
Reports
Test
Control
Program

Program
Auto Program
Advanced Program
Date and Time

Enter Password
0000

Advanced Program
Panel Operation
Panel Events
Loop Events

Panel Events
System Startup
Ground Fault
Battery Charger

System Startup
Event Notification

Active
Printer Yes<>
Dialer Account 1&2
CID 110
Network Yes<>

Network
Network 01 >
Network 02
Network 03

Network 01
Enabled Yes<>
Save
Loop event programming
Loop events, such as loop fault, map fault, and loop initialization have an event
notification setting for contact ID, dialer, NET (1-8), and printer, which controls
where the event is sent when it takes place. Each event has a factory default
setting that can be used with no additional programming.
