Chapter 3: System operation
E-FSA64 and E-FSA250 Technical Reference Manual 143
Figure 50: Internal event (panel and loop events) details display screen
Internal Event 051
Line Fault
Internal event number
Note: See “Event ID numbers and descriptions” on page 154 for a list of event
numbers.
Figure 51: Zone event details display screen
Zone 01
Lobby pull station
Zone number
Label
Note: You can scroll through the list of all devices in the zone reporting an event.
Figure 52: Annunciator event details display screen
Annunciator 007
Annunciator 007
Annunciator number
Label
To view event details:
1. When an event takes place, press Enter on the front panel.
2. View the event details.
The event details screen is displayed for 15 seconds and then returns to the
previous screen if there is no activity.
