Edwards Signaling eFSA250 - Manual (Page 238)

Appendix B: Worksheets
226 E-FSA64 and E-FSA250 Technical Reference Manual
Evenly distributed distance End-loaded distance
Sensors Modules 18 AWG 16 AWG 14 AWG 18 AWG 16 AWG 14 AWG
55 72 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
50 77 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
45 82 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
5009 ft.
(1526 m)
7958 ft.
(2425 m)
12656 ft.
(3857 m)
40 87 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
4777 ft.
(1456 m)
7689 ft.
(2343 m)
12070 ft.
(3678 m)
35 92 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
4565 ft.
(1391 m)
7253 ft.
(2210 m)
11535 ft.
(3515 m)
30 97 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
4372 ft.
(1332 m)
6945 ft.
(2116 m)
11046 ft.
(3366 m)
25 102 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
4194 ft.
(1278 m)
6662 ft.
(2030 m)
10596 ft.
(3229 m)
20 107 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
4030 ft.
(1228 m)
6402 ft.
(1951 m)
10182 ft.
(3103 m)
15 112 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
3878 ft.
(1182 m)
6161 ft.
(1877 m)
9799 ft.
(2986 m)
10 117 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
3737 ft.
(1139 m)
5938 ft.
(1809 m)
9444 ft.
(2878 ft.)
5 122 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
3607 ft.
(1099 m)
5730 ft.
(1746 m)
9113 ft.
(2777 m)
0 126 5172 ft.
(1576 m)
8217 ft.
(2504 m)
13069 ft.
(3983 m)
3512 ft.
(1070 m)
5580 ft.
(1700 m)
8875 ft.
(2705 m)
