Chapter 2: Front panel programming
E-FSA64 and E-FSA250 Technical Reference Manual 91
You can also configure Reset for a correlation group in two ways:
• Reset Activate: When an event is added to a correlation group without a
configured time delay, the output activates when the reset starts and restores
when the reset ends. When an event is added with a configured time delay,
the output activates only after the delay time is reached.
If the delay is greater than twenty seconds, the outputs will not activate, since
the delay time exceeds the reset duration.
• Reset Restore: When an event is added to a correlation group without a
configured time delay, active outputs in the correlation are restored when the
reset starts and the end of the reset activates the outputs, provided the device
triggering the output is still active; otherwise, the outputs will not activate.
When programmed with a time delay, the outputs are activated after the reset
duration and an additional delay time assigned to the correlation group,
provided the device triggering the output device is still active.
When you configure a correlation group to activate, restore, or disable with the
common outputs assigned to reset activate or restore, the priorities are defined
from highest to lowest, as shown below.
1. Device disable (command menu or user key)
2. A latched output
3. Activation or restore via command menu
4. Restore via user key
5. Activation via user key
6. Restore from correlation (reset restore)
7. Activation via correlation
To add or remove a panel event:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3 Choose Loop Configuration.
4. Choose Correlation Groups and enter the number
of the correlation group. (Values range from 001 to
199.)
5. Choose Add/Rem Panel Event.
6. Select:
Advanced Program
Loop Configuration

Loop Configuration
Loop Class
Zone
Correlation Groups

Correlation Groups
Number 001<>

Correlation Group 001
Add/Remove NAC
