To set the activation count:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3 Choose Loop Configuration.
4. Choose Correlation Groups and enter the number
of the correlation group to be programmed.
(Values range from 001 to 199.)
5. Choose Activation Count and enter the activation
count (values range from 01 to 99).
6. Choose Save.
Advanced Program
Loop Configuration

Loop Configuration
Loop Class
Zone
Correlation Groups

Correlation Groups
Number 001<>

Correlation Group 001
Add/Remove Device
Suite Sig Sil No
Activation Count

Activation Count
Number 01
Save
To copy the members of a correlation group:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3 Choose Loop Configuration.
4. Choose Correlation Groups.
5. Enter the number of the correlation group to be
programmed. (Values range from 001 to 199.)
6. Choose Copy and enter the number of the
correlation group to be copied.
7. Choose Save.
Advanced Program
Loop Configuration

Loop Configuration
Loop Class
Zone
Correlation Groups

Correlation Groups
Number 003<>

Correlation Group 003
Add/Remove Device
Suite Sig Sil No
Activation Count
Copy

Copy
From Group 001<>
Save
