Chapter 2: Front panel programming
E-FSA64 and E-FSA250 Technical Reference Manual 55
Press the Menu button to exit menu mode without
saving.
The button is now completely programmed to
unlatch all latched outputs globally.
8. If you chose Disable, press the down arrow to edit
the Control option, and indicate what the key
should control. Choose:
• Members
• Corr Grp
• Both
Press Enter to reopen the previous menu, and
then choose Save.
Note:
This option is not available for Unlatch,
Activate, or Restore.
You are now ready to choose the correlation
groups to be activated, disabled, or restored.
9. Enter the number of the first correlation group to
be assigned or unassigned, then press Enter.
• If you enter the number of a correlation group
that is already assigned to the key, the
command REM (remove) is displayed.
Pressing Enter removes the group from the list.
• If you enter the number of a correlation group
that has not yet been assigned to the key, the
command ADD is displayed. Pressing Enter to
adds the new group to the list.
Enter to Add<>
Corr Grp 001
Control Corr Grp
— or —
Enter to Add<>
Corr Grp 001
Control Members
— or —
Enter to Add<>
Corr Grp 001
Control Both

Enter to Add<>
Corr Grp 001
Control Corr Grp
— or —
Enter to Add<>
Corr Grp 001
Control Members
10. Enter the number of the next correlation group to
be added or removed, and then press Enter.
Repeat to add or remove any remaining
correlation groups.
11. When you have finished editing the list of
correlation groups, press Enter to reopen the
previous menu, and then choose Save.
— or —
Press the Menu button to cancel your changes
and exit menu mode.
