Chapter 2: Front panel programming
E-FSA64 and E-FSA250 Technical Reference Manual 117
To program CMS devices:
1. Display the panel configuration options menu. See
“Panel programming” on page 109.
2. Choose CMS Device.
3. Choose the device you want to program.
4. Program each device and option using Table 32
on page 115. For dialer options, see Table 33
below. For receiver options, see Table 34 on page
120.
5. After programming each device option, choose
Save.
6. Press the Menu button to exit menu mode, or
continue programming.
Panel Configuration
Ann. Class
Annunciator
CMS Device

CMS Device
Dialer
Network
Swngr Shtdn Rp.200<>

CMS Device
Swngr Shtdn Rp.200<>
Event Notification
Save
Dialer programming
The dialer has a number of options that you can program. Use the dialer to send
event information to the central monitoring station. You can also use it as a
modem for dial-in programming and status and report retrieval. To program the
dialer (DACT), you must install and enable the SA-DACT.
Table 33: Dialer programming options
Option
Description
Type Set the dialer type to one of the following values.
Dual line: Uses LINE 1 and LINE 2 to transmit events to the
central station receiver and performs modem functions. In this
mode, the dialer supervises and reports faults on both lines.
Single line: Uses LINE 1 only to transmit events to the central
station receiver and performs modem functions. In this mode, the
dialer supervises and reports faults only on LINE 1.
Modem only: Dialer provides interface for outbound
communications and the ability for dial-in programming and status
and report retrieval. If Modem Only is selected, only Rings to
Answer, Ring Type, and Callback Number can be programmed.
No other dialer options are displayed in the menu. The modem
function only works with LINE 1. In this mode, neither line is
supervised.
None: No dialer is installed or if a dialer is installed, disables the
dialer.
