Appendix B: Worksheets
E-FSA64 and E-FSA250 Technical Reference Manual 213
Worksheet A: Control panel current load
Devices Qty
Standby
current (mA)
Alarm
current (mA)
Qty x
Standby
current (mA)
Qty x Alarm
current (mA)
Base panel 1 See note [1]
below
See note [2]
below
Primary loop circuit
(fully loaded loop)
50 120
XAL127 loop
expander card
(fully loaded loop)
55 128
SA-CLA Class A
card
3 60
SA-232 RS-232
card
13 13
SA-DACT dialer 41 41
SA-ETH network
card
34 34
LED expander 4 1 expander:
48
2 expanders:
96
Totals (mA)
(transfer totals to Battery Calculation Worksheet)
[1] eFSA64: 155
eFSA250: 172
[2] eFSA64: 204
eFSA250: 267
