Appendix D: Applications
E-FSA64 and E-FSA250 Technical Reference Manual 267
• Do not enable in-suite signal silence.
Floor 1 Correlation
Input
Output
No in-suite
signal silence
Floor 1 dwelling and hallway inputs Floor 1 dwelling and hallway audibles
Floor 2 Correlation
Input
Output
No in-suite
signal silence
Floor 2 dwelling and hallway inputs Floor 2 dwelling and hallway audibles
Floor 3 Correlation
Input
Output
No in-suite
signal silence
Floor 3 dwelling and hallway inputs Floor 3 dwelling and hallway audibles
Floor 4 correlation
Input
Output
No in-suite
signal silence
Floor 4 dwelling and hallway inputs Floor 4 dwelling and hallway audibles
Floor 5 correlation
Input
Output
No in-suite
signal silence
Floor 5 dwelling and hallway inputs Floor 5 dwelling and hallway audibles
Creating a hallway correlation
The hallway correlation ensures that an alarm detected anywhere in the building
will turn on all audibles located in hallways throughout the building.
On the input side of this correlation, add all input devices on all floors. Include all
those inside dwelling units and all those in hallways.
On the output side, add all hallway sounders throughout the building.
Notes
• Set the alarm activation count for this correlation to 1.
• Do not enable in-suite signal silence.
Hallway Correlation
Input
Output
Occupant and hallway inputs on all floors Hallway sounders on all floors
