Chapter 2: Front panel programming
88 E-FSA64 and E-FSA250 Technical Reference Manual
To add the Common Trouble Event to a correlation group:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3. Choose Common Trouble then choose Trouble.
4. Choose Correlation Groups and enter the number
of the correlation group to be configured.
5. Press Enter to toggle between possible values:
• “Included” adds the item to the group
• “Excluded” removes the item from the group
6. Repeat steps 7 to 9 to add or remove the event
from any remaining correlation groups to be
configured.
7. Choose Save.
8. Press the Menu button to exit menu mode or
continue programming.
Trouble
Correlation Groups
Event Notification
Correlation Groups
Group 001
Status Included
Enter Exit
Setting a correlation group’s activation count
A correlation group’s activation count is the number of member activations that
are required to activate the correlation group. The activation count is used to set
up cross zoning. The following rules apply: disservice
• The count cannot exceed the number of input members in the correlation
group
• The default value is 1
• Input members can be zones, NACs, devices, unconfigured alarm events, or
the common trouble event
• The activation count must be 1 for correlation groups with in-suite signal
silence enabled
• The activation count must not exceed 2 for cross zoning applications and the
zones should not have alarm verification per ANSI/NFPA 72-2002 6.8.5.4.3.
