Chapter 2: Front panel programming
106 E-FSA64 and E-FSA250 Technical Reference Manual
To configure a relay module or base as a latched output:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3. Choose Loop Configuration.
4. Choose Device.
5. If the panel has multiple loops, choose the loop to
be configured.
6. Enter the device address to be configured. Device
details are displayed.
7. Set the Base Type option to Relay.
8. Set the Follow option to None.
9. Set the Latched option to Yes.
10. Choose Type and select one of the Latched
Outputs types listed in Table 27 on page 105.
11. Press the Menu button to exit menu mode, or
continue programming.
Loop configuration
Zone
Correlation groups
Device <>

Device
Number 001
Serial # 5199776279

Device 005/001
Base Type Relay
Follow None
Latched Yes
