Chapter 2: Front panel programming
E-FSA64 and E-FSA250 Technical Reference Manual 33
Figure 43: Correlation group operation
Correlation group
Input devices (smoke
detector, pull station) by
themselves or in a zone
Output devices and
NAC devices (strobe,
horn)
Input
device
Zone
input
device
Output
device
NAC
output
device
Activation of an input device in the correlation group
turns on every output device in the correlation group
(links input devices to output devices)
A correlation group can contain any combination of input devices, output devices,
NACs, events, and zones. Input devices, output devices, NACs, events, and
zones can be assigned to more than one correlation group. There are 199
available correlation groups. You can add a forty-character, alphanumeric
description to each correlation group.
Figure 44: Inputs and outputs to correlation groups
Correlation
group 001
Correlation
group 002
Correlation
group 003
Correlation
group 199
Zone, NAC, or
output device
Zone, NAC, or
output device
Zone, NAC, or
output device
Zone, NAC, or
output device
During auto programming the following devices are assigned to correlation group
001:
• All addressable smoke detectors
• All addressable pull stations
• All E-2WIRE modules
• All E-IDC1B (mini modules)
• Any circuit on an E-IDC2B or E-IDC1A configured with the P1 or P2 switch in
position 1 (alarm)
