viii E-FSA64 and E-FSA250 Technical Reference Manual
Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines, and internal metallic water pipe
system, if present, are connected together. This precaution may be particularly
important in rural areas.
Note: The Load Number (LN) assigned to each terminal device denotes the
percentage of the total load to be connected to a telephone loop that is used by
the device, to prevent overloading. The termination on a loop may consist of any
combination of devices subject only to the requirements that the sum of the Load
Numbers of all the devices does not exceed 100.
Minimum system requirements
The table below lists the minimum hardware requirements for each type of
system for which the control panel is listed.
Table 1: Minimum hardware requirements for applications
System
Equipment needed
Protected Premises (Local) Fire Alarm System Control panel
Appropriately sized batteries
Auxiliary Fire Alarm System, Local Energy Type Control panel
Appropriately sized batteries
CTM module
Remote Supervising Station Fire Alarm System Control panel
Appropriately sized batteries
SA-DACT or RPM module
Central Station Fire Alarm System Control panel
Appropriately sized batteries
SA-DACT or RPM module
To get started
If you are just starting out, follow the items in this checklist to prepare, install,
wire, and program your fire alarm control panel.
1. Prepare the site. Make sure the installation location is free from construction
dust and debris and extreme temperature ranges and humidity.
2. Unpack the equipment.
