Chapter 2: Front panel programming
96 E-FSA64 and E-FSA250 Technical Reference Manual
Option Description
(00-00-00-00 to 99-99-99-99)
Dialer:
Acct 1 2: Event information is sent to both dialer accounts
Acct 1: Event information is sent to dialer account one
Acct 2: Event information is sent to dialer account two
None: Event information is not sent to the dialer
NET (1-8): Yes or No. Controls whether event information is sent to the
connected networks
CID: Contact ID event code (000 to 999)
Correlation
groups
Lets you add the device to (or remove it from) one or more correlation groups.
1. Enter the number of the first correlation group to be configured.
2. To add the device to the correlation group, select Included.
— or —
3. To remove the device from the correlation group, select Excluded.
4. Repeat steps 1 to 3 for any other correlation groups to be configured.
5. When you have finished, choose Save.
The device may include a primary element, secondary element, and base,
depending on the device type and base type.
For more information, see “What is a correlation group?” on page 32.
Day sensitivity Set the daytime smoke level sensitivity to least, less, more, normal, or most.
Night sensitivity Set the nighttime smoke level sensitivity to least, less, more, normal, or most.
Day prealarm% Set the daytime prealarm percentage to Off or 50, 55, 60, 65, 70, 75, 80, or 90
percent. This is the amount of smoke that indicates a prealarm event before
an actual alarm event is indicated. The percentage is based on the sensitivity
level selected above. For example, if you select normal sensitivity and select
50 percent for prealarm, when smoke levels reach 50% of the normal smoke
level required to initiate an alarm, a prealarm event will be indicated.
Night prealarm% Set the nighttime prealarm percentage to Off or 50, 55, 60, 65, 70, 75, 80, or
90 percent. This is the amount of smoke that indicates a prealarm event
before an actual alarm event is indicated. The percentage is based on the
sensitivity level selected above. For example, if you select normal sensitivity
and select 50 percent for prealarm, when smoke levels reach 50% of the
normal smoke level required to initiate an alarm, a prealarm event will be
indicated.
Base type Set to the type of base (standard, relay, isolator, or sounder) being used with
the detector.
Follow This option controls the conditions that will activate the relay or sounder
detector base. Select from the following values.
Head: The base is controlled by the detector’s settings:
• The base activates when the detector goes into alarm, unless the detector
