Chapter 2: Front panel programming
E-FSA64 and E-FSA250 Technical Reference Manual
105
For information on assigning the unlatch command to a programmable key, see
“Setting up the programmable keys” on page 52.
Table 27: Output modules configurable as latched outputs
Output modules
E_NAC
E_RLY
[1] Relay bases support any of the following detectors: HD, PD, PDD, and PHD. To configure
the base as a latched output, configure the attached detector’s base type to “Relay” and set
the Latched option to “Yes.”
Table 28: Device types for latched outputs
Type
Description
Supervised outputs (latched)
SupOut Latch. For Class B latched output modules that
output an unsynchronized signal. Does not follow signal
silence.
Continuous nonsilenceable (latched) Cont NS Latch. For Class B latched output modules that
output an unsynchronized signal. Does not follow signal
silence.
Continuous nonsilenceable ClsA
(latched)
Cont NS ClA Latch. For Class A latched output modules
that output an unsynchronized signal. Does not follow
signal silence.
Supervised outputs ClsA (latched)
SupOut ClA Latch. For Class A latched output modules
that output an unsynchronized signal. Does not follow
signal silence.
Relay nonsilenceable (latched)
Relay Latch. For Class B relay devices functioning as
latched outputs. Does not follow signal silence.
Relay nonsilence NO (latched)
Relay NO Latch. For relay devices functioning as latched
outputs that close when activated. Does not follow signal
silence.
Relay nonsilence NC (latched)
Relay NC Latch. For relay devices functioning as latched
outputs that open when activated. Does not follow signal
silence.
