Edwards Signaling eFSA250 - Manual (Page 236)

Appendix B: Worksheets
224 E-FSA64 and E-FSA250 Technical Reference Manual
Evenly distributed distance End-loaded distance
Sensors Modules 18 AWG 16 AWG 14 AWG 18 AWG 16 AWG 14 AWG
110 17 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
105 22 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
100 27 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
95 32 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
90 37 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
85 42 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
80 47 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
75 52 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
70 57 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
65 62 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
60 67 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
55 72 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
50 77 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
45 82 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
5009 ft.
(1526 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
40 87 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
4777 ft.
(1456 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
35 92 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
4565 ft.
(1391 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
30 97 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
4372 ft.
(1332 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
25 102 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
4194 ft.
(1278 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
20 107 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
4030 ft.
(1228 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
15 112 5172 ft.
(1576 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
3878 ft.
(1182 m)
6098 ft.
(1858 m)
5952 ft.
(1814 m)
