Chapter 2: Front panel programming
E-FSA64 and E-FSA250 Technical Reference Manual
103
Note:
Depending on the type of device you are
programming, some of the options in the table
below may not be available.
7. When you finish programming an option, choose
Save, then choose the next option.
8. Press the Menu button to exit menu mode, or
continue programming.
Save
Device 001
Base Follow Device<>
Type Smoke<>
Save
Programming relay and sounder detector bases
Relay and sounder bases require some configuration not required by other
devices. First, the panel does not automatically distinguish between relay and
sounder bases — Both are set by default to base type “relay”. You must
manually change this setting for sounder bases.
In addition, configuration is required to control how these devices are activated.
Relay bases can be activated by:
• The detector to which they are attached
• One or more correlation groups
Sounder bases can be activated by:
• The detector to which they are attached
• One or more correlation groups
• The 24 volt riser
You can configure these options using the procedure given below. See Table 26
on page 95 for information on the Base and Follow options.
