Chapter 2: Front panel programming
90 E-FSA64 and E-FSA250 Technical Reference Manual
To remove all members from a correlation group:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3 Choose Loop Configuration.
4. Choose Correlation Groups.
5. Enter the number of the correlation group. (Values
range from 001 to 199.)
6. Choose Remove All. A warning message is
displayed.
7. Choose Continue to remove all members from the
group.
— or —
Press the Cancel button to return to the previous
level without removing all members.
Note: Removing all members from a correlation group
resets the activation count to 1 and disables in-suite
signal silence.
Advanced Program
Loop Configuration

Loop Configuration
Loop Class
Zone
Correlation Groups

Correlation Groups
Number 003<>

Correlation Group 001
Add/Remove Device
Suite Sig Sil No
Activation Count
Copy
Remove All

ALL GROUP MEMBERS
WILL BE LOST!
Continue
Cancel
Adding and removing panel events
The following panel events can be added to correlation groups in order to trigger
outputs in that correlation. The outputs activate at the beginning of the event and
restore when the events restore.
• Signal Silence
• Drill
• Common Alarm
• Common Supervisory
• Common Monitor
• Common Disable
• Common Trouble
• Local AC Power
• System AC Power
• Aux Power 1
• Aux Power 2
