Appendix C: Front panel menu flowcharts
E-FSA64 and E-FSA250 Technical Reference Manual
249
Advanced Program: Panel Configuration
menu
Panel Configuration
Panel NAC
Ann. Class Class A<>
Annunciator
CMS Device
Printer
IP 192.168.001.001
MSK 255.255.255.000
Lock Rmt Read Yes<>
AC Voltage 120<>
Save
Panel NAC
NAC
NAC X
Class Class A<>
Type Cont Non Sil<>
Label
Correlation Groups
Event Notification
Save
Annunciator
Annunciator 01
Annunciator 02
Annunciator 03
Annunciator 04
Annunciator 05
Annunciator 06
Annunciator 07
Annunciator 08
Advanced Program:
Panel Configuration -
CMS Device
Printer
Type Supervised<>
Event Notification
Save
Label
aaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaa
<-Save <-Back
Correlation Groups
Group XXX
Status Included
<-Enter <-Exit
Event Notification
Trouble
Disable
Test
Annunciator X
Type Off<>
Expanders 1
Label
Event Notification
Save
Trouble
Printer Yes<>
Dialer Account 1&2<>
NET (1-8) No<>
CID 110
Save
Label
aaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaa
<-Save <-Back
Trouble
Printer Yes<>
Dialer Account 1&2<>
NET (1-8) No<>
Save
Notification
Printer Yes<>
Dialer Account 1&2<>
NET (1-8) No<>
CID 110
Save
